Name: Light PCB Assembly
Brand: PCB Printed Circuit Board and PCBA manufacturing
Availability: InStock
Rating: 5 (1 reviews)

Description
Data Sheet

1. Enterprise Overview & Core Services

Maxipcb specializes in professional lighting PCB (Light PCB) assembly services, providing a full range of integrated solutions covering SMT soldering, bonding, incoming material processing, OEM services and SMT stencil fabrication. Our service scope covers the entire lighting PCB assembly process, including post-soldering, plug-in, testing and mass production.

Maxipcb offers one-stop PCB LED lighting assembly services, including product concept consultation, document support, R&D design, and customized development. We provide competitive pricing for LED PCB assembly, supporting proofing, sample production, small-batch and large-batch manufacturing, with reliable quality and on-time delivery. New and old customers are welcome to consult our lighting PCB assembly services.

2. Lighting PCB Core Material System

Maxipcb adopts high-quality substrates for lighting PCB assembly, mainly including FR4 material, aluminum-based material and copper-based material, each tailored to different application scenarios and performance requirements.

2.1 FR4 Material Lighting PCB

Lighting PCBs with widely distributed LED lamp beads typically adopt FR4 substrates. Compared with the previously used CAM-3 material, FR4 material has superior overall performance in various grades, ensuring stable electrical performance and reliability for general lighting applications.

2.2 Aluminum-Based Lighting PCB

Aluminum-based lighting PCB is a metal-based circuit board with excellent heat dissipation performance, widely used in lighting products with higher heat dissipation requirements. Generally, a single-sided aluminum-based lighting PCB consists of a three-layer structure: circuit layer, insulating layer and metal base layer.

In addition, Maxipcb also provides 2-layer aluminum-based lighting PCB design, with a structure of circuit layer, insulating layer, aluminum base, insulating layer and circuit layer. Multilayer aluminum-based lighting PCBs are rarely used due to application scenario limitations.

2.2.1 Aluminum-Based Lighting PCB Classification

According to surface finishing, aluminum-based lighting PCB assembly can be divided into tin-sprayed aluminum-based lighting PCB, anti-oxidation aluminum-based lighting PCB, silver-plated aluminum-based lighting PCB, immersion gold aluminum-based lighting PCB, etc.

According to application scenarios, it can be divided into street light aluminum-based lighting PCB, fluorescent light aluminum-based lighting PCB, LB aluminum-based lighting PCB, COB aluminum-based lighting PCB, packaged aluminum-based lighting PCB, bulb aluminum-based lighting PCB, power aluminum-based lighting PCB, automotive aluminum-based lighting PCB, etc.

2.2.2 Aluminum-Based Lighting PCB Core Advantages

Power devices are mounted on the circuit layer of the aluminum-based lighting PCB. The heat generated by the devices is quickly conducted to the metal aluminum base layer through the insulating layer, and then dissipated by the metal base layer, realizing efficient heat dissipation for the devices. Compared with traditional FR-4 circuit boards, aluminum substrates can reduce thermal resistance to an extremely low level, featuring excellent thermal conductivity; compared with thick-film ceramic circuits, they have superior mechanical properties.

In addition, aluminum-based PCBs comply with RoHS environmental standards and are more suitable for SMT process surface mounting. With the promotion of energy-saving lamps, various energy-saving and high-aesthetic LED lamps have become popular in the market, driving the large-scale application of aluminum-based lighting PCB assembly in LED lighting products.

2.3 Copper-Based Lighting PCB

Copper-based LED lighting PCB assembly has superior heat dissipation performance compared with aluminum-based PCBs, making it particularly suitable for high-heat scenarios such as automotive LED headlights, where stable heat dissipation is critical to product lifespan and performance.

3. Maxipcb Core Advantages & Service Commitment

Maxipcb is a professional provider of small and medium-batch electronic services integrated with sample production, holding authoritative certifications including IATF16949, UL, ISO9001 and SGS RoHS, ensuring the quality and compliance of lighting PCB assembly products.

With rich experience in lighting PCB R&D, design and assembly, we focus on providing customized one-stop solutions to meet the diverse needs of customers in different lighting fields. Our services cover proofing, sample verification, small-batch trial production and large-batch mass production, with reasonable pricing, strict quality control and on-time delivery.

Maxipcb adheres to the core value of quality, continuously optimizes the assembly process, improves production efficiency, and ensures that each lighting PCB product meets the technical requirements of customers. We are committed to establishing long-term cooperative relationships with new and old customers, providing professional technical support and satisfactory after-sales services, and helping customers achieve product upgrading and market competitiveness.

4. Consultation Guide

For more details about Maxipcb lighting PCB assembly services, product customization and quotation, welcome new and old customers to consult us at any time. Our professional team will provide you with tailored solutions and timely responses.

FAQ

What substrates do you support for Light PCB Assembly?
We support a range of substrates for our pcb assembly service, including FR-4, aluminum-based, and copper-based materials. This allows us to tailor solutions for various LED lighting applications while addressing heat dissipation needs, especially for aluminum substrates.

Can you customize PCB assembly for prototypes and mass production?
Yes, our printed circuit board assembly service covers the full lifecycle from prototype proofing to small-batch and large-batch manufacturing. We provide flexible production volumes, ensuring on-time delivery and consistent quality throughout all stages.

What quality control measures are in place for your circuit board assembly?
We conduct thorough PCB and PCBA testing to ensure reliability and compliance with RoHS standards. Our processes follow IPC industry norms and include rigorous post-solder inspection and functional tests to maintain high-quality circuit board assembly results.

How do you support design consultation and documentation for Light PCB Assembly?
We offer expert design concept consultation, documentation support, and customized development to fit your LED lighting PCB needs. Our collaboration includes DFM feedback and design reviews to optimize manufacturability and performance before proceeding to assembly.

Light LED PCBA

PCB layers: 1-2layers

Substrate: FR-4, Aluminum, Copper

Surface treatment: HASL lead-free / OSP

Solder resist: White

Copper thickness: 0.5oz-2oz

Silk Screen Color: Black

PCB Testing: Yes

PCBA Testing: Yes

Application: PCB LED Lighting Assembly
